YM018
You are here: Home » YM018
1
5050 1.5W RGB
5050 1.5W RGB
IP65
IP65
DMX
DMX
空白
空白
IR REMOTE
IR REMOTE
空白
空白
空白
空白
空白
2
3
4

VIDEO

PRODUCT PARAMETERS

LED Type 5050 1.5W RGB 3in1 LEDs
LED Count 480
LED Colors RGB
LED Segments 20 (2 x 10)
Strobe LED Type 3535 5W LEDs
Strobe LED Count 144
Strobe LED Colors Cool-White+Amber
Strobe LED Segments 8+8
Resolution 8-16 Bit
Tilt (Degrees) 185°
Control Modes 10CH / 20CH / 77CH
Display Illuminated graphic LCD
Protocol USITT DMX-512, RDM
RDM Bidirectional communication
Cooling Temperature controlled, overheating protection
Dimmer 0-100% electronic
Shutter electronic, max. 20 Hz
Internal Effects LED Macro Effects
Signal connection XLR 5-Pin or 3-Pin In/Out
Power Input PowerCON In/Out
Mains voltage 100-240V AC / 50-60Hz
Power 1000W
Maximum ambient temperature -30°C / 86°F, 50°C / 122°F
Operating Position any
Hanging Omega-Bracket
Safety wire attachment foldout eyelets
Single fixture (shipping) cardboard
Tourpack (shipping) 4-way Flight Case
Standard colors (housing) black
Size (carton) 58x36x19cm
Weight (carton) 10KG
Size (4in1 flight case) 94x50x49cm
Gross Weight (4in1 flight case) 57KG

PRODUCT ACCESSORIES

Flight Case
Flight Case
Fast lock
Fast lock
配件空白
配件空白
配件空白

DOWNLOAD

Name Size Downloads Update Thumbnail Copy Link Download
Mas Spot.docx 159KB 51 2025-12-05 download Copy Link Download
