| Panel LED Type | 1.5W RGB 3in1 LEDs |
| Panel LED Count | 504 |
| Panel LED Colors | RGB |
| Panel LED Segments | 14 (2 x 7) |
| Tube LED Type | 5W 6500K LEDs |
| Tube LED Count | 280 |
| Tube LED Colors | Cool-White |
| Tube LED Segments | 28 (2 x 14) |
| Movement Resolution | 8-16 Bit |
| Tilt (Degrees) | 185° |
| Control Modes | 8CH / 18CH / 25CH / 95CH / C 8CH / C 11CH / C 13CH / C 24CH / C 30 CH / C 47CH / C 68CH / C 74CH / C 97CH |
| Display | Illuminated graphic LCD Touch Screen |
| Protocol | USITT DMX-512, RDM, Art-Net, sACN |
| RDM | Bidirectional communication |
| Wireless DMX | 2.4 GHz W-DMX™ (optional) |
| Cooling | Temperature controlled, overheating protection |
| Effects Dimmer | 0-100% electronic |
| Shutter | electronic, max. 20 Hz |
| Internal Effects | LED Macro Effects |
| Signal connection | Seetronic IP65 XLR 5-Pin or 3-Pin In/Out |
| Power Input | Seetronic PowerCON TRUE1 In |
| Art-Net | RJ45 In/Out |
| Mains voltage | 100-240V AC / 50-60Hz |
| Power | 1800W |
| Maximum ambient temperature | -30°C / 86°F, 50°C / 122°F |
| Operating Position | any |
| Hanging | Omega-Bracket (Support arm side hanging) |
| Safety wire attachment | foldout eyelets |
| Folding clamps | optional |
| Single fixture | cardboard |
| Tourpack | 4-way Flight Case |
| Housing standard colors | black |
| Length | 482 mm / 18.9 in |
| Width | 178 mm / 9.0 in |
| Height (head horizontal) | 243 mm / 9.5 in |
| N.W | 13.0 kg |
| G.W | 16.0 kg |
| Size | 56x43x25cm |
