YM014
You are here: Home » YM014
1
5050 0.5W
5050 0.5W
IP65
IP65
DMX
DMX
空白
空白
IR REMOTE
IR REMOTE
空白
空白
空白
空白
空白
2
3

VIDEO

PRODUCT PARAMETERS

LED Type 5050 0.5W RGB 3in1 LEDs
LED Count 480
LED Colors RGB
LED Segments 8 (2 x 4)
Effects
Dimmer 0-100% electronic
Shutter electronic, max. 20 Hz
Internal Effects LED Macro Effects
Strobe Tube LEDs
LED Type 3535 5W 6500K LEDs
LED Count 144
LED Colors Cool-White
LED Segments 4
Resolution 8-16 Bit
Tilt (Degrees) 185°
Control Modes 7CH / 14CH / 16CH / 42CH / 44CH
Display Illuminated graphic LCD
Protocol USITT DMX-512, RDM
RDM Bidirectional communication
Wireless DMX 2.4 GHz W-DMX™ (optional)
Cooling Temperature controlled, overheating protection
12. Specification
Signal connection Seetronic IP65 XLR 5-Pin or 3-Pin In/Out
Power Input Seetronic PowerCON TRUE1 In/Out
Operating Conditions
Mains voltage 100-240V AC / 50-60Hz
Power 1000W
Maximum ambient temperature -30°C / 86°F, 50°C / 122°F
Operating Position any
Mounting Options
Hanging Omega-Bracket
Safety wire attachment foldout eyelets
Packaging & Appearance
Single fixture cardboard (inner and outer cartons)
Tourpack 4-way Flight Case
Standard colors black
Dimensions & Weight
Length 482 mm / 18.9 in
Width 178 mm / 9.0 in
Height (head horizontal) 243 mm / 9.5 in
N.W 10 kg
G.W 12.5 kg

PRODUCT ACCESSORIES

Flight Case
Flight Case
Fast lock
Fast lock
配件空白
配件空白
配件空白

DOWNLOAD

Name Size Downloads Update Thumbnail Copy Link Download
Mas Spot.docx 159KB 53 2025-12-05 download Copy Link Download
