| Lightsource | 12*10W RGBWAUV |
| Dimmer | 0-255 |
| Native lens options | 10° |
| Filters | Magnetic/Hand-tightened |
| Optional filters | 15°/20°/40° |
| LED panel | 12*10W RGBWPY |
| Color Temperature (white) | 6230K |
| Strobe | 0-20Hz adjustable |
| CRI | 73 |
| Tilt | 360° |
| AC Input | — |
| Indicator | LCD |
| Efficacy | 33 lm/W |
| Electrical protection | (O.L.P)：110%–200% of rated output power, |
| Light output all LEDs on | 2746 LM |
| hiccup Protection | automatically resumes after load normalizes |
| Light output red | 441 LM |
| (O.V.P) | Hiccup mode |
| Light output green | 920 LM |
| Input voltage,absolute max. Rating | 85～265VAC 47-63Hz |
| Light output blue | 160 LM |
| Input voltage,nominal | 85～265VAC or 120～370VDC 47-63Hz |
| Light output white | 1073 LM |
| Total power | 80W |
| Light output UV | 6.3 LM |
| Max power consumption | 80W |
| Light output amber | 368 LM |
| Constant power consumption | 73W |
| Lux @ 2m | 3602 LX |
| Power Supply Unit | (O.L.P)：110%–200% of rated output power, |
| Lux @ 5m | 576 LX |
| (O.V.P) | Hiccup mode |
| Lux @ 8m | 225 LX |
| Standby power consumption | 2.5W |
| Lux @ 10m | 144 LX |
| Self-Resetting Fuse | MF-NSMF020(1206-200mA/30V) |
| Native beam angle(s) | 24° |
| Maximum Connections | 25pcs@220VAC |
| Initial field of view (spot angle) | 38° |
| Cabled DMX | 3 pin |
| Color options | Black-RAL 9004 |
| DMX channels | 3/6/8/12 CH |
| IK rating | IK07 |
| DMX modes | 4 |
| IP class | IP65 |
| Protocol | USITT DMX512A,RDM ANSI E1.20 |
| Material | Aluminium |
| Setting and addressing | Manual settings at the display buttons/RDM |
| Lens material | PE |
| Standalone mode | 11 programs with up to 32 scenes |
| Net dimensions | 298 * 288 * 137 mm |
| Cable Length (power) | European single head waterproof power |
| Net weight | 5.1 KG |
| DMX data in/out | Seetronic-3PIN waterproof DMX |
| cable | (H0R07)1.5m*2.5mm |
| output(K3F2C-W-B)/input(J3F2C-W-B)Power Connection | Seetron-ic-waterpeoof Power input(SAC3MPX(05) )/output(SAC3FPX(05)) |
| Maximum input current | 2.2A/115VAC 1.3A/230VAC |
| Power Input/Output Connector | Seetronic-Waterproof Power Supply |
| Maximum output current | 10A/12V 5A/24V |
| Output | Black-SAC3FX |
