| LED expected lifetime | 50000H |
| Tilt locking system | yes |
| Lightsource | 16pcs*3W Red+20pcs*3W Amber+40pcs*15W WW |
| Segment control | 4 segments |
| Color Temperature (at full) | 1800K/2000K/2200K/2400K/2600K/2800K/3000K |
| Screen Type | LCD |
| CRI | 93 |
| Efficacy | 18 lm/W |
| Light output all LEDs on | 7567 lm |
| Light output Amber | 369 lm |
| Light output WW | 7398 lm |
| Lux @ 2m | 2055 lx |
| Lux @ 5m | 329 lx |
| Lux @ 8m | 128 lx |
| Lux @ 10m | 82 lx |
| Native beam angle(s) | 57° |
| Initial field of view (spot angle) | 91° |
| Color options | Fine sand black(Black-RAL 9004) |
| IK rating | IK07 |
| IP class | IP65 |
| Material | Aluminium |
| Net dimensions | 405*395*240mm |
| Net weight | 13.52kg |
| Color calibration | 127-255 |
| Dimming curve | Linear/Square Law/Inverse Square Law/S-Curve |
| Dimmer | 0-255% |
| LED panel | 4*4pcs*3W Red+4*5pcs*3W Amber+4*10pcs*15W WW |
| Strobe | pulse/random pulse/opening pulse/closing pulse/random opening pulse/random closing pulse/burst/random burst pulse |
| Strobe Speed | 0 - 20Hz adjustable |
| Tilt | 0-90° |
| Electrical protection | Overload protection, output overvoltage protection, over-temperature protection |
| Input voltage, absolute max. Rating | 100 - 240VAC 50/60Hz |
| Input voltage, nominal | 100 - 240VAC 50/60Hz |
| Max inrush current 240V AC | 60A |
| Total Power | 650W |
| Max power consumption | 642W |
| Constant power consumption | 408W |
| Power factor | PF = 0.99 |
| Power Supply Unit | Overload protection, output overvoltage protection, over-temperature protection |
| Standby power consumption | 8W |
| Maximum Connections | 5 pcs@220V 2 pcs@110V |
| 16-bit control | yes |
| Cabled DMX | 3 pin/5 pin XLR input/output |
| DMX channels | 1/2/4/5/8/9/12/18/11/20CH |
| DMX modes | 10 |
| Protocol | USITT DMX512/RDM ANSI E1.20 |
| Setting and addressing | Manual settings at the display buttons/RDM |
| DMX data in/out | Seetronic 3PIN in＆out(C3F2C-W) |
| Power Connection | Seetronic SAC3PX（New） |
| Power Input/Output Connector | Seetronic-Waterproof Power Supply Output Black-SAC3FX |
| Cable Length (power) | European single head waterproof power cable（H0R07)1.5m*2.5mm² |
| Max. Input Current | 8.5A |
| +42V Max. Output Current | 16A |
| +12V Max. Output Current | 2A |
