LED Color | White |
LED Color Temperature | 6500K |
LED CRI level | 80 |
Quantity of white LED | 96*1W |
Quantity of tri LED | 384*0.5W |
Dimming frequency | 600/1200/2400/4800/9600/18000HZ |
Dimmer resolution | 16bit |
Optical DMX Channel Range | 3/9/22/36/50/92CH |
Beam angle | 90° |
Output @1M | 9000 lux |
Output @5M | 600lux |
Heat management Cooling type | Passive cooling |
MAX. Ambient temp (Ta max) | 40°C |
MIN. Ambient temp (Ta min) | -20°C |
MAX housing temp.(ta=25℃) | 58.5°C |
MAX housing temp.(ta=40℃) | 67°C |
Interface TFT displayer | present |
Software upload method | XLR |
Installation Orientation | Any |
IP rating | IP65 |
Net product weight | 6 kg |
Machine Dimensions – Length | 1000 mm |
Machine Dimensions – Width | 90 mm |
Machine Dimensions – Height | 113 mm |
Included items | Power cable, Manual |
Approved certifications | CE, RoHS |
Auto program | Yes |
Static Color | Yes |
Manual Calibration | No |
Factory calibration | No |
Strobe speed | 0 – 20Hz |
Effects | Yes |
Control Protocol | USITT DMX512/1990 |
RDM | Yes |
RDM compliance | ANSI/ESTA E.120 |
WDMX | Optional |
DMX input connection | DMX 5 pin in & out |
Electricity Input Voltage & Rate | 100-240VAC, 50/60Hz |
Nominal Total Power Consumption | (at Nominal voltage 230V) 140W |
Typical Current | (at Nominal voltage 230V) 1.363A |
Power Plug Type | Seetronic PowerCON True |
Name | Size | Downloads | Update | Thumbnail | Copy Link | Download |
---|---|---|---|---|---|---|
AH012B User manual.pdf | 5.19MB | 0 | 2025-08-13 | | Copy Link | Download |
