AH023B
You are here: Home » AH023B
1
AMBER+WW
AMBER+WW
Display
Display
IP65
IP65
DMX
DMX
空白
空白
RDM
RDM
Pixel control
Pixel control
DIM
DIM
Master Slave by Wireless
Master Slave by Wireless
空白
空白
2
3
4
5

VIDEO

PRODUCT PARAMETERS

LED 2 X 150W LED, Amber 1700K+WW 2500K
Structure Die-cast aluminum structure
Features LED pixel control, with fast lock, turnable filter, display inverted
Cooling Waterproof fan for heat dissipation
Beam Angle 50°
Update Method Via DMX signal to update
Channels 01/02/05/10CH
Protocols DMX512, RDM
Power Connector Seetronic TRUE one connector IP65
Data Connector 3 or 5PIN XLR
Display LCD Display
Programs 7 built-in programs
Strobe 1 ~ 20Hz
Dimming Modes 4 kinds
Effect Tungsten effect
Power Rated power: 350 W
Voltage AC 110V ~ 240V 50/60Hz
IP Rating IP65
Work Environment -40℃ ~ 45℃
Startup Environment -20℃ ~ 45℃
Cooling Fan Static waterproof fan, intelligent speed control
Temperature Protection Intelligent temperature protection to ensure LED service life
Size 400 × 254 × 245 mm
Net Weight 8 kgs

PRODUCT ACCESSORIES

Charge case
Charge case
Magnetic cover
Magnetic cover
Frost filter
Frost filter
110 Fast lock
110 Fast lock
Safety rope
Safety rope
空白

DOWNLOAD

Name Size Downloads Update Category Thumbnail Copy Link Download
AH023 User manual.pdf 15.47MB 0 2025-08-15 download Copy Link Download
